Simplex 4098-9764 Multi Sensor Detector with Base

About Simplex 4098-9764 Multi Sensor Detector with Base

The Simplex 4098-9854 and 4098-9764 are addressable multi-sensor detectors designed for use in fire alarm systems. Here are some key features:
Key Features
1. Combination Smoke and Heat Detection: Both detectors combine smoke and heat sensing technologies to provide accurate and reliable detection.2. Addressable: Both detectors are addressable, allowing for precise location identification in the event of an alarm.3. Multi-Criteria Detection: The detectors use multiple criteria, including smoke, heat, and humidity, to determine the presence of a fire.4. False Alarm Reduction: Advanced algorithms and multi-sensor technology help reduce false alarms.5. Compatibility: Compatible with Simplex fire alarm control panels.
Technical Specifications
1. Sensitivity: Adjustable sensitivity settings to accommodate different environments.2. Operating Temperature: 32F to 100F (0C to 38C).3. Humidity: Up to 95% relative humidity.4. Power Requirements: 15-32 VDC.
Certifications and Listings
1. UL 268: Listed for smoke detectors.2. UL 521: Listed for heat detectors.3. FM Approved: Approved by Factory Mutual.

Compact Design

The Simplex 4098-9764 is engineered for compact integration, featuring a lightweight construction and small dimensions for optimal functionality.


High Temperature Tolerance

With a temperature range of up to 50C, this sensor device delivers consistent performance even in demanding conditions.
